The new Frontier HD X models offer stunning high definition viewing with incredible colour control and phase correction. First class lens coatings on all surfaces throughout the binocular and dielectric coated prisms ensure the highest amount of light transmission.
All Frontier HD X binoculars pass through a strict quality control inspection to ensure all aspects match design intent. They are optically checked for resolution, light transmission and Strehl Ratio for optical image formation. They are further tested in extreme operational temperature conditions from -15°C to +55°C and storage temperatures -40°C to +70°C. Final checks of waterproofing to IPX7 and fog proofing are tested.
STUNNING HIGH DEFINITION VIEWING
First class lens coatings on all surfaces throughout the binocular and dielectric coated prisms ensure the highest amount of light transmission. Lenses feature a hydrophobic coating to repel water.
Optical System System H7
Magnification 10x
Objective Lens 42mm
Colour Green
Lens Coating Wide Band, Anti-reflection, Fully Multi-Coated Lenses
with Water Repellent Coating
Field of View 112m @1000m
Field of View 6.4°
Apparent Field of View 64°
Eye Relief 15mm
Exit Pupil 4.2mm
Interpupillary Distance 56 - 74mm
Close Focus 2.5m
Prism Type Roof
Prism Glass BAK 4
Prism Coating Dielectric Mirror Coating
Eye Cups Twist-Up (Replaceable)
Diopter Type Right Eye
Tripod Mounting Thread Yes (¼" - 20 UNC)
Height 140mm
Width 105 - 123mm
Weight 725g
