Highlights:
APO Lenses
Extra-low Dispersion (ED) glass
Dielectric Coatings
High resolution phase corrected BAK-4 roof prisms
Water repellent lens coatings
Magnesium alloy chassis
Focus from 2m
Replaceable twist-up eye cups with position stops
Stay-on lens covers
All Frontier models feature Hawke’s H7 optics, offering stunning high definition viewing with incredible colour control and phase correction.
High performance lens coatings and Dielectric Coated prisms ensure the highest level of light transmission.
The Frontier APO offers extreme clarity, flat field vision along with excellent chromatic aberration control for a stunning wide angle image.
APO models benefit from Extra-low Dispersion glass for controlled chromatic aberration and the elimination of colour fringing.
Objective Lens 42mm
Color Green
Magnification 10x
Optical System System H7
Field of View 8.1°
Eye Relief 0.7in 18mm
Exit Pupil 0.21″ 5.3mm
Lens Coating Wide Band, Anti-reflection, Fully Multi-Coated Lenses
with Water Repellent Coating
Field of View 142m @1000mtrs
Apparent Field of View 65°
Interpupillary Distance 58-78mm
Close Focus 2m
Prism Type Roof
Prism Glass BAK 4
Eye Cups Twist-Up (Replaceable)
Diopter Type Right Eye
Tripod Mounting Thread Yes (¼" - 20 UNC)
Height 141mm
Width 109 - 130mm
Weight 740g
